GsBP-5MS GC Columns

Phase
Poly(5% diphenyl, 95% dimethylsiloxane), cross-linked and bonded

USP code
Equivalent to USP G27, G36

Features
Solvent rinse-able and high temperature limit
Exceptionally low column bleed, inert and neutral surface, and high plate number
Wide range of column dimensions and stationary phase film thicknesses for GC and GC/MS
Non-polar
General columns for most popular applications, particularly environmental, chemical, pharmaceutical, and
agricultural applications, as well as food and drug related applications and many others. Ideal column for
new method development

Similar Phases
DB-5MS, HP-5MS, Ultra-5, SLB-5, Rxi-5MS, Rxi-5sil MS, Rxi-5HT, VF-5MS, CP-Sil 8CB low bleed MS,
BPX-5, ZB-5MS, ZB-5HT, AT-5MS, Optima-5MS

Product List


P/N	Description	Length (m)	ID (mm)	Film (um)	Temperature Limit (C)
1520-1203	GsBP-5MS, 12m x 0.20mm x 0.33um	12	0.20	0.33	-60 to 325/350
1520-1703	GsBP-5MS, 17.5m x 0.20mm x 0.33um	17.5	0.20	0.33	-60 to 325/350
1520-2503	GsBP-5MS, 25m x 0.20mm x 0.33um	25	0.20	0.33	-60 to 325/350
1520-5003	GsBP-5MS, 50m x 0.20mm x 0.33um	50	0.20	0.33	-60 to 325/350
1525-1501	GsBP-5MS, 15m x 0.25mm x 0.10um	15	0.25	0.10	-60 to 325/350
1525-1502	GsBP-5MS, 15m x 0.25mm x 0.25um	15	0.25	0.25	-60 to 325/350
1525-1505	GsBP-5MS, 15m x 0.25mm x 0.50um	15	0.25	0.50	-60 to 325/350
1525-1510	GsBP-5MS, 15m x 0.25mm x 1.00um	15	0.25	1.00	-60 to 325/350
1525-3001	GsBP-5MS, 30m x 0.25mm x 0.10um	30	0.25	0.10	-60 to 325/350
1525-3002	GsBP-5MS, 30m x 0.25mm x 0.25um	30	0.25	0.25	-60 to 325/350
1525-3005	GsBP-5MS, 30m x 0.25mm x 0.50um	30	0.25	0.50	-60 to 325/350
1525-3010	GsBP-5MS, 30m x 0.25mm x 1.00um	30	0.25	1.00	-60 to 325/350
1525-6001	GsBP-5MS, 60m x 0.25mm x 0.10um	60	0.25	0.10	-60 to 325/350
1525-6002	GsBP-5MS, 60m x 0.25mm x 0.25um	60	0.25	0.25	-60 to 325/350
1525-6005	GsBP-5MS, 60m x 0.25mm x 0.50um	60	0.25	0.50	-60 to 325/350
1525-6010	GsBP-5MS, 60m x 0.25mm x 1.00um	60	0.25	1.00	-60 to 325/350
1532-1501	GsBP-5MS, 15m x 0.32mm x 0.10um	15	0.32	0.10	-60 to 325/350
1532-1502	GsBP-5MS, 15m x 0.32mm x 0.25um	15	0.32	0.25	-60 to 325/350
1532-1505	GsBP-5MS, 15m x 0.32mm x 0.50um	15	0.32	0.50	-60 to 325/350
1532-1510	GsBP-5MS, 15m x 0.32mm x 1.00um	15	0.32	1.00	-60 to 325/350
1532-2505	GsBP-5MS, 25m x 0.32mm x 0.52um	25	0.32	0.52	-60 to 325/350
1532-3001	GsBP-5MS, 30m x 0.32mm x 0.10um	30	0.32	0.10	-60 to 325/350
1532-3002	GsBP-5MS, 30m x 0.32mm x 0.25um	30	0.32	0.25	-60 to 325/350
1532-3005	GsBP-5MS, 30m x 0.32mm x 0.50um	30	0.32	0.50	-60 to 325/350
1532-3010	GsBP-5MS, 30m x 0.32mm x 1.00um	30	0.32	1.00	-60 to 325/350
1532-6001	GsBP-5MS, 60m x 0.32mm x 0.10um	60	0.32	0.10	-60 to 325/350
1532-6002	GsBP-5MS, 60m x 0.32mm x 0.25um	60	0.32	0.25	-60 to 325/350
1532-6005	GsBP-5MS, 60m x 0.32mm x 0.50um	60	0.32	0.50	-60 to 325/350
1532-6010	GsBP-5MS, 60m x 0.32mm x 1.00um	60	0.32	1.00	-60 to 325/350
1553-3005	GsBP-5MS, 30m x 0.53mm x 0.50um	30	0.53	0.50	-60 to 300/320
1553-3008	GsBP-5MS, 30m x 0.53mm x 0.88um	30	0.53	0.88	-60 to 300/320
1553-3015	GsBP-5MS, 60m x 0.53mm x 1.50um	30	0.53	1.50	-60 to 300/320
